VT 08
|
VT-08 LA
|
VT-08BASS
|
Audio parameters
|
Sound type
|
Double 8-inch line array stereo
|
Single-15-inch suspension compensation for ultra-low-frequency audio
|
Frequency response (-3dB)
|
60Hz - 18kHz
|
45Hz - 300Hz
|
Sensitivity (1W@1m) Low frequency
|
94dB
|
99dB
|
Sensitivity (1W@1m) high frequency
|
109dB
|
|
Maximum sound pressure level program rate is low frequency
|
129dB
|
123dB
|
Maximum sound pressure level program power is high frequency
|
132dB
|
|
Projection Angle
|
100°x 10°
|
|
Continuous power is low-frequency
|
500W
|
800W
|
Continuous power and high frequency
|
120W
|
|
Program power is low in frequency
|
1000W
|
1400W
|
High-frequency of program power
|
240W
|
|
Peak power is low in frequency
|
2000W
|
2800W
|
Peak power is high-frequency
|
480W
|
|
Impedance low frequency / HF
|
16 Ohms / 16 Ohms
|
8 Ohm
|
Low pitch
|
2X8" Neodymium magnetic medium-bass unit
|
1x15"Neodymium magnetic bass unit
|
high pitch
|
1X3"Neodymium magnetic treble unit
|
|
Frequency Distribution Points @ -3dBspl
|
1250Hz
|
|
High pitch protection
|
PPS © + Compressor
|
|
working temperature
|
20 C to 40 C (dust cover required to prevent water, dust, direct sunlight)
|
Physical parameters
|
Connector
|
2x NL 4
|
2x NL 8
|
Dimensions (high x width x deep)
|
625mm x240mm x 412mm
|
615mm x 495mm x 705mm
|
Net weight
|
24.35KG
|
51.25KG
|
Rough weight
|
27.7KG
|
60KG
|
Veil
|
Black environmental paint
|
Box material
|
Maritime birch splint
|
Hang
|
Special galvanized steel pendant
|
